This Comprehensive Optics Package Gives You the Right Tools from Point Blank to Long Range
This kit saves you $40 vs purchasing the components individually!
More information on the LEOS and 4xDM Magnifier below:
About the LEOS Red Dot with Laser Sight:
The Ultimate Red Dot System that won’t break the bank. Now available with Red Laser or Green Laser!
- Crisp 2 MOA red dot
- Brilliant red targeting laser with W/E adjustment
- Integrated riser mount housing
- 50K hour max battery life
- Flip up lens caps
- Tool-free windage & elevation adjustments
- Backed by the AT3 Lifetime Warranty
The AT3 LEOS™ is ideal for home defense, tactical & law enforcement, hunting, plinking, competitive shooting, or any shooting scenario where magnification is not required. Optimized for AR-style rifles, sporting & hunting rifles, shotguns, air rifles, and any other weapon with a Picatinny or Weaver mounting rail.
Accurate
- Crisp 2 MOA red dot with 6 brightness settings for accurate both-eyes-open shooting
- Brilliant red laser enables rapid targeting – perfect for home defense, tight quarters, & low visibility
- Crystal-clear fogproof multi-coated optics resist scratches and provide clarity in all situations
- Unfailingly maintains zero – even with high-caliber weapons
Versatile
- Precise digital controls for simple control of the sight and integrated laser – switch between red dot only, red dot laser, and laser only modes with the push of a button.
- Integrated riser mount puts sight at optimal eye level, and provides lower 1/3 cowitness with AR-15 iron sights (compatible with all AR iron sight setups including fixed sights)
- Tool-free windage and elevation adjustment with integrated screwdriver on W/E caps
- Spring-assisted flip-up lens caps provide rapid deployment and superb lens protection
Reliable
- Durable 6061 Aircraft-Aluminum housing with a stealthy matte-black hardcoat anodized finish
- Fully waterproof and fogproof – sealed design with nitrogen purged optics
- Extra-long battery life – up to 50,000 hours on lowest brightness setting (red dot only); up to 40 hours of continuous red laser use, and 8 hours of continuous green laser use.
- Shockproof circuitry rated for impacts up to 800 G’s – it can handle any recoil you throw at it.
- Uses commonly available CR123 lithium batteries – One included
- Easy thumb screw for secure mounting to any picatinny rail (can tighten by hand, or with a coin or flathead screwdriver)
- Backed by the AT3 Lifetime Warranty
Technical Specifications:
- Power / Obj. Lens: 1x30mm
- Reticle: 2 MOA Red Dot
- Lens Coating: Multi-coated
- Mount height: 1.58” from rail to center of sight tube (Lower 1/3 cowitness with AR iron sights)
- Battery life: up to 50,000 hours on lowest setting; up to 40 hours of continuous laser use
- Battery Type: CR123A (included)
- Weight: 8.3 oz
- Mounting Length: 1.1 inch / 28 mm
- Total Length/Width/Height: 4.3 in / 2.3 in / 3.1 in
- Windage/Elevation Click Value: 1 MOA per click
- Adj Range: /- 50 MOA (total adjustment range 100 MOA)
- Parallax Free: 25 yds
- Eye Relief: Unlimited
- Field of View: Unlimited
- Night Vision Compatible: No
- Nitrogen filled: Yes
- Shockproof: Yes
- Waterproof/Fogproof: Yes
- Red Laser Wavelength – 632-650nm
- Red Laser power: <5mw class IIIa
- Green Laser Wavelength – 532nm
- Green Laser power: 5mw class IIIb
- Finish: Matte black anodized
LEOS Instruction ManualInside of the box:
- LEOS™ Red dot sight
- Instruction sheet
- Lens cloth
- Surefire™ CR123A Battery
About the 4xRDM Magnifier:
Go from fast up close to precise at long range, with AT3’s new 4x Magnifier with QD Mount
Experience the latest and greatest AT3 Red Dot Magnifier, with a new Quick Detach mount and a crystal-clear 4x magnification for any AT3 Red Dot Sight
Versatile
- Easy upgrade to extend the range of any red dot sight with 4X magnification
- Quickly transition between short- and long-range shooting scenarios. Just push the button and flip the magnifier over.
- Spacers are included for Absolute and Lower 1/3 Cowitness Red Dot Sights – whatever your sight height, the magnifier will work!
- The Quick Detach Mount means you don’t need to carry extra weight if the job doesn’t demand it – just flip the lever to add or remove
Accurate
- Crystal-clear multi-coated optics for a sharp sight picture
- Adjustment screws make it simple to center the red dot in the sight picture
- Fast focus adjustment ensures a crisp sight image
Durable
- Sturdy flip-to-side mount with positive locking mechanism, made of durable 6061 T6 aluminum matte anodized finish
- Shockproof optic is built to withstand recoil of any weapon, including shotguns and large-caliber rifles
- Scratch-resistant optical coating
- Backed by the AT3 Lifetime Warranty
Important fit note:
This magnifier is designed for use with the AT3 RD-50 PRO and LEOS Red Dot Sights, as well as many other sights that use riser mounts. The included spacers correspond to most “Absolute Cowitness” and “Lower 1/3 Cowitness” riser heights for red dot sights. Installation of either spacer is simple, and allows you to have more accurate
Specifications:
- Magnification: 4x
- Objective Lens Diameter: 32 mm
- Height: 1.4in from the base center of optic (Absolute Cowitness). With use of spacer, height is 1.57in
- Eye Relief: 2.5 in
- Exit Pupil: 7.0mm
- Field of View: 49 ft @ 100 yds
- Length: 4.6in
- Weight: 12oz with mount
- Optics Coating: Fully multi-coated
- Material – 6061 T6 anodized aluminum
- Included in the box: QD flip to side mount, 4X magnifier, Hex key, Stamped Wrench, Lens Cleaning Cloth, Spacers, and mounting screws
